Slotted Shaft
We take a φ10 mm, 40Cr material, HRC 35 slotted shaft as an example. The double shear failure load is ≥25 kN. This force is enough for excavator links or hydraulic cylinder ears. The outer diameter tolerance can be h6, h7, g6, or m6. That is ±0.005 mm to ±0.020 mm.
Get Precision Positioning with Our Slotted Shaft
Do you need to locate parts or handle shear forces? Screws are not good for this. Our Slotted Shaft is made for precision positioning and power transmission. It has no threads. It is just a cylinder. You use it for connecting rods, guide posts, and rotation shafts. We are a Shanghai factory. We have supplied fasteners for 20 years.
Check Our Shear Load Data and Tolerance Levels
We take a φ10 mm, 40Cr material, HRC 35 slotted shaft as an example. The double shear failure load is ≥25 kN. This force is enough for excavator links or hydraulic cylinder ears. The outer diameter tolerance can be h6, h7, g6, or m6. That is ±0.005 mm to ±0.020 mm. Surface roughness is Ra≤0.8 μm. h6 is for high precision locating or sliding fits. g6 is for rotating fits with some gap. m6 is for interference fits. Those parts do not come out after installation. We make three types of shafts. Plain shafts are for excavator links and hydraulic cylinder ears. Slotted shafts work with a cotter pin or a retaining ring. This lets you remove the joint. Knurled shafts press into plastic handles or aluminum housings. They work as fixed rotation shafts. The slot width tolerance is ±0.05 mm. The knurl depth is 0.2 to 0.4 mm. The knurled section length is 5 to 15 mm. The knurled outer diameter is 0.1 to 0.3 mm bigger than the base diameter.
|
Parameter |
Standard / Value |
|
Double Shear Load (φ10mm, 40Cr) |
≥ 25 kN |
|
Diameter Tolerance Options |
h6, h7, g6, m6 (±0.005 to ±0.020 mm) |
|
Surface Roughness |
Ra ≤ 0.8 μm |
|
Knurling Depth |
0.2 - 0.4 mm |
Why Our R&D and Delivery Work for You
We have our own R&D team. You can share your special needs. We will help solve your technical problems. Mass production takes 2-3 weeks for standard parts. Custom products take 4 weeks. Repeat orders are even faster. Payment is 30% deposit and 70% balance. We take US dollars. Big orders get discounts. Free samples are ready for stock items. We offer stainless steel SUS304, SUS316, or SUS440C and carbon steel 45#, 40Cr, or SCM435. Carbon steel gets heat treatment. Hardness can be HRC 28-36 or HRC 45-52. Surface finish includes black oxide, zinc plating, or hard chrome plating. Hard chrome raises surface hardness to HV 800-1000. We pack your order well. We have done this for 20 years.
The entire product line is fully customizable.
